Features
Vertical rotation and side-to-side oscillation of abrasive brushes.
No deformation of the hole.
Controlled by touch screen and process controller.
Adjustable brush pressure.
Auto Zero Procedure
Variable brush speed.
Adjustable speed of conveyor belt.
Roughness of the copper surface can be controlled by a combination of different brush particle sizes.
Separate console.
Laser measurement of board thickness.
Functions
Abrasive Cured Plugging Resin.
Metal Surface Treatment.
Remove sharp corners, hole edges, and burrs from irregular board edges.
Specifications
Operating width | 640 mm |
Working height | 900 mm |
line speed | 0.3-3 m/min |
Max. panel size | W640 * L∞mm |
Min. panel size | 250 * 350 mm |
Max. panel thickness | 10 mm |
Min.panel thickness | 0.5 mm (Minimum bracket thickness for special plates:0.3mm) |
Size | 2100* 900 *1645 mm |
Use of power supply | 9KW (400 volt 3phase 50 Hz) 11KW(480 V – 3ph – 60 Hz) |
Water consumption (with filter) | 0.4 – 0.8m3/h |
1.2 – 1.5 m3/h（unfiltered） |
